Rhino Test

What does "Zoo" refer to in Rhino?

THE ZOO IS A TYPE OF RENDER FARM.

THE ZOO IS BACKUP CLOUD STORAGE.

THE ZOO IS A FILE SHARING SYSTEM.

THE ZOO IS A FLOATING LICENSE MANAGER.

When is a surface not developable?

WHEN IT HAS NO CURVATURE

WHEN IT HAS SINGLE CURVATURE

WHEN IT HAS INTERIOR CUTOUTS OR HOLES

WHEN IT HAS COMPOUND CURVATURE

What does the Variable Fillet Surface command require?

IT REQUIRES THAT TWO SURFACE EDGES TOUCH OR INTERSECT BEFORE EXECUTION.

IT REQUIRES TWO SURFACES TO BE PARALLEL AND PERPENDICULAR BEFORE EXECUTION.

IT REQUIRES THAT TWO SURFACE EDGES ARE AT AN ANGLE BEFORE EXECUTION.

IT REQUIRES THAT TWO SURFACE EDGES DO NOT INTERSECT.

G1 is what type of continuity?

POSITION

TANGENCY

PLANAR ACCELERATION

CURVATURE

G0 is what type of continuity?

CURVATURE

POSITION

PLANAR ACCELERATION

TANGENCY

Is there an order that you need to observe when using the Matchsrf command?

YES, FROM THE SMALLER SURFACE TO THE LARGER SURFACE.

NO, THERE IS NO SIGNIFICANT DIFFERENCE.

YES, FROM THE UNTRIMMED SURFACE TO THE TRIMMED SURFACE.

YES, FROM THE TRIMMED SURFACE TO THE UNTRIMMED SURFACE.

What is the primary function of the Crv2View command in the most direct terms?

IT CREATES ONE OR MORE CURVES FROM TWO PLANAR CURVES EXISTING IN DIFFERENT VIEWS.

IT CREATES ONE PLANAR CURVE FROM THE EDGES OF A SURFACE FROM TWO VIEWS.

IT CREATES ONE CURVE FROM MULTIPLE CURVES EXISTING IN TWO DIFFERENT VIEWS.

IT CREATES ONE CURVE FROM TWO PLANAR CURVES EXISTING IN DIFFERENT VIEWS.

In basic terms, what does the ExtractIsocurves command do?

IT CREATES THE SIMPLEST CURVE IN THE U, V, OR BOTH DIRECTIONS PRECISELY ON A SELECTED SURFACE.

IT CREATES THE SIMPLEST CURVE IN THE U OR V DIRECTION PRECISELY ON A SELECTED TRIMMED SURFACE.

IT "PULLS" THE SIMPLEST CURVE IN BOTH THE U AND V DIRECTIONS PRECISELY ON A SELECTED SINGLE SURFACE.

IT CREATES THE SIMPLEST CURVE IN THE U OR V DIRECTION ADJACENT TO THE SELECTED SURFACE.

When using NetworkSrf, what does edge matching determine?

HOW THE EDGES BEHAVE WHEN TRIMMED

HOW THE CONTINUITY IS RESPECTED IN THE UNTRIMMED GEOMETRY

HOW THE EDGES MATCH THE INPUT GEOMETRY

HOW THE EDGES MATCH SPLITTING CURVES

You are unsure about where you are in a command. What should you check first?

THE RHINO WEBSITE

THE MANUAL

THE COMMAND LINE

THE HELP TOPICS

What does the Zebra command accomplish?

IT ENABLES HOLE DETECTION VISUALLY IN SURFACE GEOMETRY BY MEANS OF A STRIPE MAP.

IT TRANSFORMS THE SURFACE INTO ALTERNATING STRIPES FOR FORM AND DESIGN EVALUATION.

IT DIVIDES THE SURFACE INTO EVENLY SPACED STRIPES FOR MEASURING IN THE U OR V DIRECTIONS.

IT ENABLES SURFACE CONTINUITY AND SMOOTHNESS EVALUATION VISUALLY BY MEANS OF A STRIPE MAP.

What are polysurfaces in Rhino?

TWO OR MORE SURFACES THAT ARE JOINED BUT DISTINCTLY DIFFERENT

TWO OR MORE SURFACES THAT ARE GROUPED

TWO OR MORE GROUPED SURFACES THAT EXIST IN ALL THREE AXES

TWO OR MORE SURFACES THAT ARE JOINED

What does the CSec command create?

CROSS-SECTION CURVES FROM MULTIPLE SURFACES IN DIFFERENT VIEWS

CROSS-SECTION CURVES THROUGH PROFILE CURVES

CROSS-SECTION CURVES FROM CLOSED POLYSURFACES

CROSS-SECTION CURVES FROM OPEN POLYSURFACES

When saving a command to a button, what does using the underscore (_) ensure?

IT ALLOWS THE COMMAND LINE ENTRIES TO BE RECORDED IN HISTORY.

IT ALLOWS A COMMAND TO BE UNDONE AT A LATER DATE.

IT ENSURES THE COMMAND RUNS AS AN ENGLISH-LANGUAGE COMMAND NAME.

IT ESTABLISHES A COMMAND AS A STANDALONE COMMAND.

What is the most basic type of fillet called?

SCRIBED LINE FILLET

ROLLING BALL FILLET

RAIL FILLET

SOFTEN FILLET

What defines a lightweight extrusion object?

A CURVE, A SEAM, AND A DIRECTION

A PROFILE CURVE, A SURFACE, AND AN ISOCURVE

A SURFACE, A RAIL, AND A CROSS SECTION

A PROFILE CURVE, A DIRECTION, AND DISTANCE

What best describes the inherent qualities of a NURBS surface?

A RIGID DOME THAT EXTENDS TO INFINITY

A CIRCULAR OR OVAL SHEET THAT STRETCHES

A FOUR-SIDED SHEET THAT STRETCHES

A SIX-SIDED SHEET THAT STRETCHES

What does Flip Normals (Windows) or Flip All (Mac) alter in the Offsetsrf command?

IT CHANGES THE DISTANCE THE SURFACE WILL BE OFFSET.

IT CHANGES THE CONTINUITY OF THE OFFSET.

IT CHANGES THE DIRECTION IN WHICH THE SURFACE WILL BE OFFSET.

IT CHANGES WHETHER THE OFFSET WILL BE A SURFACE OR SOLID.

With the Gumball option On, how do you move objects with the gumball?

SELECT THE OBJECT, THEN HOLD THE ALT KEY (WINDOWS) OR OPTION KEY (MAC) AND DRAG THE APPROPRIATE ARROW.

RIGHT-CLICK THE OBJECT, THEN DRAG THE APPROPRIATE ARROW.

SELECT THE OBJECT, THEN TYPE "GUMBALL" IN THE COMMAND LINE AND ENTER THE DISTANCE VALUE.

SELECT THE OBJECT, THEN DRAG THE APPROPRIATE GUMBALL ARROW.

How can you change your project's unit of measurement?

CLICK OPTIONS > GENERAL (WINDOWS) OR EDIT > CHANGE DEGREE (MAC).

CLICK FILE > CHANGE UNITS (WINDOWS) OR TOOLS > FILE UTILITY (MAC).

CLICK OPTIONS > UNITS (WINDOWS) OR FILE > SETTINGS > UNITS (MAC).

CLICK OPTIONS > GENERAL > MODE (WINDOWS) OR FILE > REVERT TO (MAC).

You want to create evenly spaced copied of objects along the X, Y, and Z axes. What command would you use?

SCATTER

PROJECTTOCPLANE

MAELSTROM

ARRAY

When is the best time to model with Record History turned on?

WHEN MODELING A PREDETERMINED DESIGN

WHEN COMPUTING RESOURCES ARE LIMITED

AT THE EXPLORATION PHASE OR EARLY STAGES OF MODELING

IN THE LAST STAGES OF A DESIGN

Why would you want to flip normals on an individual curve?

TO MATCH THE NORMALS WITH THE DIRECTION OF OTHER CURVES USED FOR SURFACE CREATION

TO DUPLICATE THE CURVE AND ADD IT TO ANOTHER LAYER

TO ALIGN THE MIDPOINT OF ONE CURVE TO A GROUP OF CURVES

TO INDICATE THE SURFACE OFFSET DIRECTION PRIOR TO EXECUTING THAT COMMAND

What is the standard way to reset the gumball to default settings?

DOUBLE-CLICK THE MENU BALL WHILE HOLDING DOWN THE SHIFT KEY.

TURN THE GUMBALL ON AND OFF IN THE MODELING AIDS.

CLICK THE MENU BALL AND THEN SELECT RESET GUMBALL.

SELECT THE GUMBALL WHILE PRESSING THE ESC KEY.

You are creating a new file in Rhino. How can you start the file in millimeters?

CLICK FILE > NEW FILE FROM METRIC (WINDOWS) OR FILE > NEW METRIC FILE (MAC).

CLICK FILE > METRIC.

CLICK FILE > NEW FILE FROM TEMPLATE (WINDOWS) OR FILE > NEW USING TEMPLATE (MAC).

CLICK FILE > IMPORT.

What is the most significant difference between VariableFilletSrf and VariableBlendSrf?

THE OPTIONS AVAILABLE FOR EACH ARE EXTREMELY DIFFERENT AND SHOULD BE NOTED.

THE MANNER IN WHICH THE COMMANDS ARE EXECUTED DIFFERS GREATLY.

THE CONTINUITY TYPE OF SURFACE GENERATED IS DIFFERENT AND HAS FORM CONSEQUENCES.

THE PRECONDITIONS CAN BE EXTREMELY DIFFERENT FOR EACH AND ARE CASE DEPENDENT.

Why would you use the PictureFrame command?

TO TRACE AN OBJECT FROM A REFERENCE IMAGE

TO WRAP A PHOTO ON A CLOSED POLYSURFACE

TO EXTRUDE A TEXTURE ON A SURFACE USING AN IMAGE

TO MODEL A FRAMED IMAGE USING PAINT

What kind of object snaps are available mid-command when drawing geometry?

ONE-SHOT

PERSISTENT

VIRTUAL

PERSISTENT AND ONE-SHOT

Which statement best describes what CurveBoolean does?

IT JOINS OPEN POLYSURFACES TO CREATE CLOSED CURVES.

IT CREATES CLOSED CURVES FROM CLOSED POLYSURFACES.

IT CREATES CLOSED POLYSURFACES FROM OPEN CURVES.

IT CREATES CLOSED POLYLINES FROM OVERLAPPING CURVES.

What conditions must be present to use the Cap command?

THERE MUST BE AN OPENING WHERE TWO OBJECTS HAVE BEEN JOINED.

THERE MUST BE AN OPENING THAT IS CONTAINED ON ONE SURFACE THAT IS NOT COMPOUND.

THERE MUST BE A HOLE THAT DOES NOT HAVE A SEAM.

THERE MUST BE A HOLE OR OPENING THAT HAS A FLAT, PLANAR BOUNDARY CURVE.

Can open curves, surfaces, and polysurfaces be joined to make closed polysurfaces?

IT DEPENDS ON TOLERANCE SETTINGS.

NO, THESE OBJECTS CANNOT BE JOINED.

YES, BUT ONLY IF THE FORMS ARE RECTILINEAR.YES,

YES, THESE OBJECTS CAN BE JOINED.

What does BlendCrv do?

BLENDCRV CONNECTS TWO CURVES, CREATING A LOWER DEGREE CURVE BETWEEN TO HIGH DEGREE CURVES.

BLENDCRV CONNECTS TWO CURVES, MAINTAINING CONTINUITY AUTOMATICALLY.

BLENDCRV CONNECTS TWO CURVES, ALLOWING FOR CONTINUITY CONTROL BEFORE ACCEPTING THE RESULT.

BLENDCRV CONNECTS TWO CURVES AND IMPROVES CONTINUITY BY AVERAGING EVERY OTHER DEGREE.
